Seatex 10 - Lavtaps HFFR DNV-godkjent koaksialkabel for marin bruk

50m trommel

SeaTex 10 is a very flexible low loss and halogen-free communications coaxial cable perfectly designed to use for marine and offshore applications. It is worldwide approved for shipbuilding (DNV GL certificate) and is suitable for use on ships, oil platforms, wind turbines and the entire maritime area. The jacket of the SeaTex 10 is made of a special thermoplastic copolymer (SHF2), which ensures that the cable is highly resistant to heat, cold, oils, salt-water, UV radiation and has a long service life in harsh environmental conditions. The design of the SeaTex 10 is based on the successful Ecoflex 10 coaxial cable. It has excellent attenuation values, its flexibility and its small bending radius allow installation in limited spaces. Thus SeaTex 10 combines the advantages of Ecoflex coaxial cables with the special requirements in marine area. The product is specified up to 6 GHz and can be used in a temperature range from -55°C to 85°C.

Characteristics

• Conductor/screen material according to DIN EN 13602 Cu-ETP-R
• Screen material according to DIN EN 13602 Cu-ETP-A
• Insulation material according to ISO 6722-1 Chap. 5.14, Class “A”, bending diameter 120 mm
• Jacket material according to IEC 60092-360 (IEC 60092-359) SHF2
• Wall thickness of the cable jacket according to IEC 60092-376
• Flame-retardant according to IEC 60332-3-22 (Cat. A)
• Flame-retardant according to IEC 60332-1-2
• Oil-resistant according to EN 60811-2-1 (24 hrs/100°C)
• RoHS compliant (Directive 2011/65/EC & 2015/863/EU RoHS 3)
• Fire-resistant, low smoke, halogen-free (LSZH)
• Corrosivity of the combustion gases according to IEC 60754-2
• Smoke density according to IEC 61034
• UV-resistant
• Approved for marine and offshore applications
• DNV certificate no. TAE00001JX
