TEKTELIC KONA Enterprise - LoRaWAN® Gateway with Embedded Network Server

IP67, LTE, Integrated antennas, BACnet/Modbus/MQTT support

Model: MOENMLEU868 - Enterprise gateway with integrated LoRaWAN Network Server

The TEKTELIC KONA Enterprise LNS Gateway is a compact, carrier-grade LoRaWAN® gateway designed for small to mid-size enterprises, university campuses, commercial farming, and multi-building complexes. This variant features an integrated LoRaWAN Network Server (LNS) that runs entirely on-premise, eliminating the need for external cloud services or network servers. The gateway delivers complete network server functions locally, making it ideal for building automation, industrial automation, and smart manufacturing applications where data security and local control are essential.

With built-in protocol integration for BACnet/IP, Modbus TCP, MQTT, and REST API, the KONA Enterprise LNS Gateway seamlessly connects LoRaWAN® sensors directly to Building Management Systems (BMS), SCADA platforms, and industrial control systems without requiring additional middleware. The gateway includes integrated LoRaWAN, cellular (LTE), and GPS antennas within its IP67-rated enclosure, along with support for optional external antennas for enhanced coverage in challenging deployments. Simple plug-and-play installation via IEEE 802.3af PoE ensures rapid deployment with minimal configuration.

Key Features

• Embedded LoRaWAN Network Server
• Complete on-premise network server, device manager, and application server integrated in the gateway
• Web-based KONA Link interface for device provisioning, network monitoring, and payload codec management
• Eliminates dependency on external cloud services or network servers
• Native Building & Industrial System Integration
• Built-in BACnet/IP server for direct BMS integration
• Modbus TCP support via Node-RED for PLC and SCADA connectivity
• MQTT, HTTP, and REST API for application server integration
• Carrier-Grade Reliability
• MTBF of 900,000 hours (over 100 years)
• IP67-rated enclosure for demanding outdoor installations
• Operating temperature range: -40°C to +60°C
• Integrated Connectivity
• 8-channel LoRaWAN® radio with up to 27 dBm TX power
• Integrated LTE Cat-6 cellular modem with dual SIM support
• Built-in LoRaWAN, cellular, and GPS antennas
• Optional external antenna support for extended coverage

Typical Applications

• Building Automation & Smart Buildings
• HVAC control and energy management via BACnet/IP integration
• Indoor air quality monitoring and demand-controlled ventilation
• Occupancy monitoring and space optimization
• Industrial Automation
• Equipment monitoring and predictive maintenance
• Process control via Modbus TCP integration
• Asset tracking across warehouses and manufacturing facilities
• Campus & Multi-Building Networks
• University campus IoT networks for security and facility management
• Multi-building complex centralized monitoring and control
• Commercial farming and agricultural monitoring

Technical Specifications

Additional Features

• Simple onboarding via TEKTELIC LeapX mobile application
• Remote software upgrades with active and passive image management
• Integrated firewall and access control lists for enhanced security
• Multiple mounting options: pole, wall, tower, building, DIN rail

Certifications & Standards

• CE (RED 2014/53/EU)
• Safety: EN/IEC 62368-1
• LoRa Alliance certified
