Hikvision DS-2DE2A404IW-DE3/W - 4MP PTZ Network Wi-Fi Camera
4MP Resolution, 4× Optical Zoom, Wi-Fi, IP66, IK10, 20m IR
The Hikvision DS-2DE2A404IW-DE3/W(S6) is a versatile indoor PTZ network camera that combines high-resolution imaging with flexible positioning capabilities. This 4-megapixel camera delivers exceptional image clarity and is designed for reliable surveillance in various indoor environments, including corridors, offices, factories, retail stores, and restaurants.
Featuring DarkFighter technology and 120 dB Wide Dynamic Range (WDR), this camera ensures clear imaging in challenging lighting conditions, from low-light environments to scenes with strong backlighting. The 4× optical zoom combined with pan-tilt functionality provides comprehensive coverage of monitored areas, while the built-in IR illumination enables effective night-time surveillance up to 20 meters.
KEY FEATURES
- Advanced Imaging Technology
- 4 MP high-resolution imaging with powered-by-DarkFighter technology
- 120 dB Wide Dynamic Range for balanced exposure in challenging lighting
- Clear night vision with up to 20m IR range
- Professional PTZ Capabilities
- Pan range: 0° to 355°, tilt range: 0° to 90°
- 4× optical zoom with 16× digital zoom
- 300 preset positions with automatic patrolling
- Robust Design
- IP66 rated for dust and water resistance
- IK10 vandal protection for enhanced durability
- Built-in Wi-Fi for flexible installation options
Typical Applications
- Commercial Environments
- Retail stores and shopping areas
- Office buildings and corridors
- Restaurant and hospitality venues
- Industrial Settings
- Manufacturing facilities
- Warehouses and storage areas
Technical Specifications
Camera Specifications
| Specification |
Value |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Maximum Resolution |
2560 × 1440 |
| Focal Length |
2.8 to 12 mm |
| Min. Illumination |
Color: 0.005 Lux @ (F1.5, AGC ON)
B/W: 0.001 Lux @ (F1.5, AGC ON)
0 Lux with IR |
| Field of View |
Horizontal: 96.7° to 31.6°
Vertical: 51.1° to 17.7°
Diagonal: 115.1° to 36.3° |
| Power Supply |
12 VDC, Max. 11.2 W; PoE (802.3af) |
| Operating Environment |
-20 °C to 60 °C (-4 °F to 140 °F)
Humidity: 90% or less (non-condensing) |
Additional Features
- Smart Features
- Face detection and line crossing detection
- Intrusion and region entrance/exit detection
- Motion detection and video tampering alarm
- Network Features
- H.265+/H.265/H.264+/H.264 video compression
- Support for multiple network protocols
- Up to 20 simultaneous live view channels
Certifications & Standards
- IP66 environmental protection
- IK10 vandal protection
- TVS 4000V lightning protection
- IEEE802.11b/g/n Wi-Fi compatibility
